| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | PIONEERTEX |
| Certification: | ISO9001 |
| Model Number: | CSB GCCM |
| Minimum Order Quantity: | 500 Square Meter/Square |
| Price: | $2.68 - $2.98 / Square Meter |
| Packaging Details: | Exporting standard PP woven fabric packaging outside |
| Supply Ability: | 500 Square Meter/Square Meters per Day |
| Quantity: | |
|---|---|
CONCRETE EROSION CONTROL MAT (CECM)
PIONEERTEX
6810999000
| Thickness: | 5mm, 8mm,10mm,13mm,20mm | Product Name: | Cement Sand Blanket Gccm Rolls |
|---|---|---|---|
| Color: | White/white Black | Application: | River Bank Protection, Fish Pond |
| Keyword: | Concrete Mat | Port: | Nanjing/shanghai Port Or Qingdao Port |
| High Light: | Filter Point Revetment Mattress,Anti scour Revetment Mattress,Woven Revetment Mattress | ||
Who are we?
We, PioneerTEX is a professional manufacturer of GCL, Concrete Cement Cloth GCCM, woven geotube and Nonwoven geobag in China.
We could produce many types of Flexbile Concrete Blanket as below:
1. Cement Canvas made of 3D spacer fabric and concrete mixture;
2. Concrete Mat Cloth made of 3D spacer fabric, woven and nonwoven geotextile, HDPE geomembrane backing;
3. Cementex GCCM rolls is Concrete mat cloth without HDPE backing;
4. Cement sand blanket(Concrete Erosion Mat) without 3D spacer fabric, but with short fiber reinforcement,
| PIONEERTEX CEMENT-SAND BLANKET (CSB) GCCM ROLLS TECHNICAL SPECIFICATION | |||||
| PIONEERTEX CEMENT-SAND BLANKET GCCM ROLLS was mechanically needle punch bonded composite, | |||||
| consist of cement-sand mix,embedded and fixed between two layers of geotextile, and it is also reinforced | |||||
| by quilt stitched. | |||||
| PROPERTIES OF GEOTEXTILE | TEST METHOD | VALUE | |||
| Carrier layer- PP woven geotextile and geogrid composite | EN ISO 9864 | 230G/M2 | |||
| Cover layer-PET nonwoven geotextile and geogrid composite | EN ISO 9864 | 300G/M2 | |||
| PROPERTIES OF CONCRETE | TEST METHOD | VALUE | |||
| Chemical Composition | N/A | sand-cement mixture+ 2% short fiber | |||
| Density | Typical | 1.5g/cm3 | |||
| Setting start | PN-EN 196-3 | > 120 min | |||
| PROPERTIES OF CSB GCCM | TEST METHOD | VALUE | |||
| Tensile Strength MD/CMD | EN ISO 10319 | > 20 KN/M(+/-10%) | |||
| CBR Puncture Strength | ASTM C 109-02 | >3.0 KN(+/-10%) | |||
| Compressive Strength | EN ISO 14617 | 40MPa | |||
| Bending Strength | EN ISO 12467 | 3-5Mpa | |||
| Water Permeability | EN ISO 12467 | no drop of water | |||
| durability against freeze-thaw | EN ISO 12467 | R>0.75 pass | |||
| durability against heat-rain | EN ISO 12467 | R>0.75 pass | |||
| durability against warm water | EN ISO 12467 | R>0.75 pass | |||
| durability against soak-dry | EN ISO 12467 | R>0.75 pass | |||
| Reaction to fire | EN 12467 | B-S1,dO | |||
| Standard Roll Dimensions | Typical Value | ||||
| Thickness | 5-15mm | ||||
| Width x Length/Roll | 2.0X5M or 2.0X10M or 2.0X20M/ROLL | ||||
| Thickness: | 5mm, 8mm,10mm,13mm,20mm | Product Name: | Cement Sand Blanket Gccm Rolls |
|---|---|---|---|
| Color: | White/white Black | Application: | River Bank Protection, Fish Pond |
| Keyword: | Concrete Mat | Port: | Nanjing/shanghai Port Or Qingdao Port |
| High Light: | Filter Point Revetment Mattress,Anti scour Revetment Mattress,Woven Revetment Mattress | ||
Who are we?
We, PioneerTEX is a professional manufacturer of GCL, Concrete Cement Cloth GCCM, woven geotube and Nonwoven geobag in China.
We could produce many types of Flexbile Concrete Blanket as below:
1. Cement Canvas made of 3D spacer fabric and concrete mixture;
2. Concrete Mat Cloth made of 3D spacer fabric, woven and nonwoven geotextile, HDPE geomembrane backing;
3. Cementex GCCM rolls is Concrete mat cloth without HDPE backing;
4. Cement sand blanket(Concrete Erosion Mat) without 3D spacer fabric, but with short fiber reinforcement,
| PIONEERTEX CEMENT-SAND BLANKET (CSB) GCCM ROLLS TECHNICAL SPECIFICATION | |||||
| PIONEERTEX CEMENT-SAND BLANKET GCCM ROLLS was mechanically needle punch bonded composite, | |||||
| consist of cement-sand mix,embedded and fixed between two layers of geotextile, and it is also reinforced | |||||
| by quilt stitched. | |||||
| PROPERTIES OF GEOTEXTILE | TEST METHOD | VALUE | |||
| Carrier layer- PP woven geotextile and geogrid composite | EN ISO 9864 | 230G/M2 | |||
| Cover layer-PET nonwoven geotextile and geogrid composite | EN ISO 9864 | 300G/M2 | |||
| PROPERTIES OF CONCRETE | TEST METHOD | VALUE | |||
| Chemical Composition | N/A | sand-cement mixture+ 2% short fiber | |||
| Density | Typical | 1.5g/cm3 | |||
| Setting start | PN-EN 196-3 | > 120 min | |||
| PROPERTIES OF CSB GCCM | TEST METHOD | VALUE | |||
| Tensile Strength MD/CMD | EN ISO 10319 | > 20 KN/M(+/-10%) | |||
| CBR Puncture Strength | ASTM C 109-02 | >3.0 KN(+/-10%) | |||
| Compressive Strength | EN ISO 14617 | 40MPa | |||
| Bending Strength | EN ISO 12467 | 3-5Mpa | |||
| Water Permeability | EN ISO 12467 | no drop of water | |||
| durability against freeze-thaw | EN ISO 12467 | R>0.75 pass | |||
| durability against heat-rain | EN ISO 12467 | R>0.75 pass | |||
| durability against warm water | EN ISO 12467 | R>0.75 pass | |||
| durability against soak-dry | EN ISO 12467 | R>0.75 pass | |||
| Reaction to fire | EN 12467 | B-S1,dO | |||
| Standard Roll Dimensions | Typical Value | ||||
| Thickness | 5-15mm | ||||
| Width x Length/Roll | 2.0X5M or 2.0X10M or 2.0X20M/ROLL | ||||
