| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | PIONEERTEX |
| Model Number: | GT400 |
| Minimum Order Quantity: | 25 Bag/Bags |
| Price: | $500.00 - $2,000.00 / Bag |
| Packaging Details: | pp woven standard packaging |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 5 Bag/Bags per Day |
| Quantity: | |
|---|---|
DAM GEOTUBE
PIONEERTEX
591190
| Geotextile Type: | Woven Geotextiles | Product Name: | PP Woven Water Filled Dams Protection Cover |
|---|---|---|---|
| Color: | Black | Application: | Protection Water Tank Dams |
| Size: | Made To Order | MOQ: | 25pcs |
| Technology: | Special Flat Woven Technology | Raw Material: | PP Tape Yarn |
| Port: | Changzhou Port Or Shanghai Port | ||
| High Light: | PP Woven Geotube Breakwater,400g/M2 Geotube Breakwater,Water Tank Dams Dewatering Geotube | ||
We, PioneerTEX is a professional manufacturer of geotube and geobag in China.
We could produce many types of geotube and geobag as per customer's project request.
All bags and fabrics could be customized.
PIONEERTEX Geotube & Geobag Product List are as below:
What is a Geotube?
PioneerTEX GeoTube (PioTube) dewatering bag is a containment system designed for dewatering a wide variety of sludge types and sands.
It is integrated with single or multiple pieces of PioneerTEX's high-strength synthetic technical fabric and is theoretically applicable to diverse dimensions.
How do a PioneerTEX Geotube work?
Gravimetric drainage of the sludge is accompanied by a volume reduction.
Due to the special opening size of the geotextile fabric used to form the tube, the solid components of sludge are captured inside the tube whereas the water can escape from the geo-tube.
Is Polymer Flocculant Necessary for Dewatering?
Normally, tt is necessary to add polymer flocculant for dewatering, which should be added to the slurry before pumping it into the tube.
The purpose of the polymer additives is to flocculate the fines, and to increase the dewatering efficiency.
Can we do a trial on the geotube before purchasing?
Yes, of course! We will make one small model bag for your trial. Small Geotube size is 50cmX50cm.
Based on the results of preliminary field testing with small PioTube,the appropriate amount of additives can be defined.
What is GT300 geotube?
PioneerTex Sludge Dewatering Geotube-PioTube GT300 was designed and developed for some low cost dredging job or project. It was made of PP tape yarn and PP round yarn. And its flow rate is also good. Since its fabric weight is less than standard GT500 fabric, Max. Filling height of geotube is not more than 1.6mts.
GT400 data sheet is as below:
| Material: PP mono/Fabrillated Yarn woven geotextile for Geotube | ||||
| Material Quality Code: PIONEERTEX-GT300 | ||||
| Mechanical Properties | Test Method | Unit | Typical Value | |
| MD | XD | |||
| Tensile Strength | ASTM D 4595 | KN/M | 70 | 70 |
| Elongation at break | ASTM D 4595 | % | 25 | 25 |
| Seam Strength | ASTM D 4884 | KN/M | 35 | |
| CBR Puncture Strength | ASTM D 6241 | KN | 5 | |
| Hydraulic Poperties | Test Method | Unit | Typical Value | |
| Opening Size(AOS) | ASTM D 4751 | mm | 0.4 | |
| Flow Rate | ASTM D 4491 | l/min/m2 | 800 | |
| Anti-UV(500hours) | ASTM D 4355 | % | 85 | |
| Physical Properties | Test Method | Unit | Typical Value | |
| Mass Per Unti Area | ASTM D5261 | G/M2 | 400 | |
Exporting standard PP woven fabric packaging outside without pallet.
PIONEERTEX specialize in woven and nonwoven geotextile new product development and manufacturing since 2001.
We are able to develope different types of woven geo-textile or other technical woven fabric based on customer's special
request.
