| Place of Origin: | China |
|---|---|
| Brand Name: | PioneerTEX |
| Certification: | ISO9001 and ISO14001 |
| Model Number: | 1.0mm |
| Minimum Order Quantity: | 2000SQM |
| Price: | 1.5-2.9 US$/SQM |
| Packaging Details: | PP WOVEN FABRIC OUTSIDE |
| Delivery Time: | 3-4WEEKS |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 2000SQM/DAY |
| Quantity: | |
|---|---|
Composite Geomembrane
PIONEERTEX
3920109010
| Color: | Black Or White | Thickness: | 1.0mm HDPE Geomembrane |
|---|---|---|---|
| Nonwoven: | PP Or PET 100-800gsm | Woven: | PP Woven Or Filament Woven Geotextile |
| Weight: | 1000g/m2-1800g/m2 | Width: | 5.8mts |
| High Light: | Nonwoven Hdpe Smooth Geomembrane,1.0mm Hdpe Smooth Geomembrane,Pond Liner breathable roofing felt | ||
1.0mm smooth or textured HDPE Geomembrane or Membrane Composite with Nonwoven Geotextile Price for Fish Farm Pond liner
What is HDPE Geomembrane?
Geomembrane is a kind of waterproof material with basic raw material of high molecular polymer. It is mainly divided into LDPE geomembrane, HDPE geomembrane, and all kinds of composite geomembrane.
Complete variety of specifications of width and thickness. Thickness: 0.2-2.0mm.
Excellent environmental stress resistant cracking performance.
Excellent performance of chemical erosion resistance.
Big scope of application temperature and long service life .
Low Permeability :HDPE lining systems are secure because leachate does not penetrate them Methane gas will not escape from the HDPE cover system .and rainwater will not infiltrate.
Chemical Resistance:HDPE ,resistant to a wide range of chemicals ,is not threatened by typical solid or hazardous waste leachates.It is also suitable for sludge and secondary containment around chemical storage facilities
Ultraviolet Resistance:HDPE's resistance to UV exposure is further enhanced by the addition of carbon black .Additionally ,with the absence of plasticizers ,volatilization is not a problem.
HDPE Geomembrane Application:
1.Used in landfill, river embankment, lake dam, tailing dam, sewage dam and reservoir area, channels and other hydraulic ponds.
2. Anti-seepage & lining for subway, basement and tunnel.
3. Saline seepage-proofing for roadbed and other foundation.
4.Used in level seepage-proofing bedding of embankment and dam, vertical impermeable layer for foundation, construction cofferdam, fertilizer plant.
5.Used in sea water & freshwater aquaculture.
6.Used in the foundation of road, highway & railway; the waterproof layer of expansive soil and collapsible loess.
7.Used in roof seepage-proofing.
| SMOOTH HDPE GEOMEMBRANE TECHNICAL SPECIFICATION | |||||
| Property | Test Method | 40 Mil 1.0mm | 60 Mil 1.5mm | 80 Mil 2.0mm | 100 Mil 2.5mm |
| Thickness, mils | ASTM D 5199 | ||||
| minimum average | 40 | 60 | 80 | 100 | |
| lowest individual reading | 36 | 54 | 72 | 90 | |
| Sheet Density, g/cc | ASTM D 1505/D 792 | 0.94 | 0.94 | 0.94 | 0.94 |
| Tensile Properties 1 | ASTM D 6693 | ||||
| 1. Yield Strength, lb/ in | 84 | 126 | 168 | 210 | |
| 2. Break Strength, lb/ in | 152 | 228 | 304 | 380 | |
| 3. Yield Elongation, % | 12 | 12 | 12 | 12 | |
| 4. Break Elongation, % | 700 | 700 | 700 | 700 | |
| Tear Resistance, lb | ASTM D 1004 | 28 | 42 | 56 | 70 |
| Puncture Resistance, lb | ASTM D 4833 | 72 | 108 | 144 | 180 |
| Stress Crack Resistance 2, hrs | ASTM D 5397 (App.) | 300 | 300 | 300 | 300 |
| Carbon Black Content 3, % | ASTM D 1603 | 2.0 - 3.0 | 2.0 - 3.0 | 2.0 - 3.0 | 2.0 - 3.0 |
| Carbon Black Dispersion 4 | ASTM D 5596 | ||||
| Oxidate Induction Time (OIT) | |||||
| Standard OIT, minutes | ASTM D 3895 | 100 | 100 | 100 | 100 |
| Oven Aging at 85°C | ASTM D 5721 | ||||
| High Pressure OIT | ASTM D 5885 | 80 | 80 | 80 | 80 |
| (% retained after 90 days) | |||||
| UV Resistance 5 | GRI GM11 | ||||
| High Pressure OIT 6 | ASTM D 5885 | 50 | 50 | 50 | 50 |
| (% retained after 1600 hrs) | |||||
| Seam Properties | ASTM D 6392 | ||||
| (@ 2 in/min) | |||||
| 1. Shear Strength, lb/ in | 80 | 120 | 160 | 200 | |
| 2. Peel Strength, lb/ in - Hot Wedge | 60 | 91 | 121 | 151 | |
| - Extrusion Fillet | 52 | 78 | 104 | 130 | |
| Roll Dimensions | |||||
| 1. Width (feet): | 23 | 23 | 23 | 23 | |
| 2. Length (feet) | 750 | 500 | 375 | 300 | |
| 3. Area (square feet): | 17,250 | 11,500 | 8,625 | 6,900 | |
| 4. Gross Weight (pounds, approx.) | 3,470 | 3,470 | 3,470 | 3,470 | |
| PioneerTEX Composite Geomembrane Liner Specification | ||||||||
| Test Properties | BCM4 | BCM5 | BCM6 | BCM7 | BCM8 | BCM9 | BCM10 | |
| Weight | g/m2 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 |
| SPEC | 1 layer geotextile+ 1 layer membrane | 150/0.25 | 200/0.3 | 300/0.3 | 300/0.4 | 300/0.5 | 400/0.5 | 400/0.6 |
| 2 layer geotextile+ 1 layer membrane | 100/0.2/100 | 100/0.3/100 | 150/0.3/150 | 200/0.3/200 | 200/0.4/200 | 200/0.5/200 | 250/0.5/250 | |
| Mechanical Properties | Break Strength (KN/M) | 5 | 7.5 | 10 | 12 | 14 | 16 | 18 |
| Break Elongation(%) | 30-100 | |||||||
| CBR Burst Strength(KN) | 1.1 | 1.5 | 1.9 | 2.2 | 2.5 | 2.8 | 3 | |
| Tear Strength(KN) | 0.15 | 0.25 | 0.32 | 0.4 | 0.48 | 0.56 | 0.64 | |
| Peel Strength(N/cm) | 6 | |||||||
| 1 layer geotextile+ 1 layer membrane | 0.4 | 0.5 | 0.6 | 0.8 | 1 | 1.2 | 1.3 | |
| 2 layer geotextile+ 1 layer membrane | 0.5 | 0.6 | 0.8 | 1 | 1.2 | 1.4 | 1.5 | |
| Color | HDPE Geomembrane | BLACK or WHITE | ||||||
| Nonwoven Geotextile | BLACK or WHITE | |||||||
| Woven Geotextile | BLACK or WHITE | |||||||
| ROLL DIMENSION | ||||||||
| Width | 1-6m | |||||||
| Length | 50-200m/Roll | |||||||
