| Place of Origin: | China |
|---|---|
| Brand Name: | PioneerTEX |
| Certification: | ISO9001 and ISO14001 |
| Model Number: | WeldGrid |
| Minimum Order Quantity: | 2000 sqm |
| Price: | 0.5US$/sqm |
| Packaging Details: | PP woven fabric packing outisde |
| Delivery Time: | 2-3weeks |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000sqm/Day |
| Quantity: | |
|---|---|
BIAXIAL WELDED
PIONEERTEX
392590
| Name: | PP/PET Belt Welded Geogrid For Soft Soil Foundation | Material: | PP Or PET Plastic Belt |
|---|---|---|---|
| Width: | 6mts | Color: | Black Or Green |
| Use: | For Soft Soil Foundation | Feature: | 100KN M |
| High Light: |
PP/PET Plastic Belt Welded Geogrid Strength up to 100KN/M for soft soil or foundation reinforcement
What is PP/PET Welded Geogrid?
PP/PET Welded Geogrid are PP/PET belt welded geogrid, It use PP or PET as raw material, through extruding to be rib belt which with very high tensile strength,then the belts are welded by Ultrasonic welding machine to make it have high tensile strength in both Longitudinal and Transverse direction. This products mainly used for Soil stabilization, road sub-base reinforcement, aggregates confinement and improving the performance of road anti-pressure ability.
Product Features:
* high intensity;
* bending folding, good anti-fatigue, anti-corrosion, continuous rolling;
* the role of soil friction force large, application scope, suitable for high-load engineering
use.
Product Applications:
soft foundation of roads, railways, bridges, docks, dams, landfills and anti-cracking of retaining wall and roads. roadbed, embankment, road shoulder, cutting, abutment, tunnel, gateway, channel and slope of road and railway, environmental protection, embankment project, reservoir and dam, municipal construction, foundation treatment, airport, tailing dam, freight yard, inland port and pier, earthquake proof construction, military protection works, etc.
TECHNICAL SPECIFICATION
| Item | PioneerTEX PP/PET Plastic Belt Welded Geogrid | ||||||||
| 30-30 | 40-40 | 45-45 | 50-50 | 60-60 | 80-80 | 100-100 | 200-200 | ||
| Tensile strength (KN/M) | MD | 30 | 40 | 45 | 50 | 60 | 80 | 100 | 200 |
| CMD | 30 | 40 | 45 | 50 | 60 | 80 | 100 | 200 | |
| Elongation at Yield (%) | MD | 8% | |||||||
| CMD | 8% | ||||||||
| Tensile strength (KN/M) @ 2% Strain | MD | 11 | 14 | 16 | 18 | 22 | 32 | 55 | 110 |
| CMD | 13 | 17 | 20 | 23 | 28 | 36 | 55 | 110 | |
| Tensile strength (KN/M) @ 5% Strain | MD | 15 | 22 | 25 | 28 | 35 | 52 | 65 | 130 |
| CMD | 15 | 20 | 24 | 26 | 32 | 52 | 65 | 130 | |
| Peeling Strength at Welded Point | 300-500N | ||||||||
| Width | 6mts | ||||||||
