| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | pioneertex |
| Model Number: | PioneerFelt |
| Minimum Order Quantity: | 1000 Kilogram/Kilograms |
| Price: | $1.82 - $2.98 / Kilogram |
| Packaging Details: | exporting standard PP woven fabric outside |
| Supply Ability: | 1000 Kilogram/Kilograms per Day |
| Quantity: | |
|---|---|
| Geotextile Type: | Non-Woven Geotextiles | Product Name: | Needle Punched Nonwoven Geotextiled |
|---|---|---|---|
| Color: | White Or Black | Material: | PP(polypropylene) PET (polyester) |
| Weight: | 100-800gsm | MOQ: | 1 Metric Ton |
| Width: | 2mts, 4mts Or 6mts | Application: | Filtration Drainage Reinforcement Cushion |
| Port: | Nanjing Port Or Shanghai Port | ||
| High Light: | Drainage Non Woven Geotextile,Staple Fiber Non Woven Geotextile,Non Woven Geotech Fabric | ||
PP Staple Fiber Needle Punch Nonwoven Geotextile for GEOBAG, separation,reinforcement and drainage
Who are we?
PioneerTEX specialize in manufacturing different kinds of Needle Punch nonwoven fabrics which is made by 100%PP or 100%PET or mixture of PP and PET or Rayon staple fiber in different colors such as Black,White,Grey or Tan. All needle punch nonwoven more than 200gsm can be nap-raised to make fuzzy style.
PioneerTEX is dedicated to providing the highest quality products to its customers. Our needle-Punch Nonwoven Geotextile was produced out according to inner quality manual strictly from the receipt of raw materials to the finished product.
PioneerTEX PP Staple fiber Needle punch nonwoven geotextile was made of 100% virgin Polypropylene Staple fiber with good anti-UV stabilizer, and needle punching to crate the internal stable network with high strength and low elongation. All manufacturing process will be controlled strictly by computer automatically from fiber opening and calendar.
| PP Needle Punch Nonwoven Felt or Geotextile | |
| Product General Specification | |
| Color | Black, White, Grey or made to order |
| Material | 100% Virgin PP staple fiber |
| Temperature Resistance | -30 ° to +80 ° C |
| Width | 1M,1.2M,1.5M,2M,3M,4mts,5mts,6mts |
| Rolled Products | 50M,100mts,200mts,500mts,600mts |
| Thickness | 1.0mm,2mm,2.5mm,3.5mm,5.5mm,7mm |
| Delivery | 2-3Weeks after received T/T advance |
| Payment | 30% deposit, the rest by T/T or L/C |
After-treatment:
1. High temperature calendar treatment (Heat set),
2. One side cystal gum, or anti-slip dotted gum.
3. One side coated by PVC membrane.
We can also develop different kinds of needle punch nonwoven composite based on customer's technical request or sample.
| PioneerTEX PP Staple Fiber Needle Punch Non-Woven Geotextile Specification | ||||||||||||
| PROPERTY | UNIT | TEST METHOD | GT-131 3.1 oz | GT-135 3.5 oz | GT-140 4.0 oz | GT-142 4.5 oz | GT-160 6 oz | GT-170 7 oz | GT-180 8 oz | GT-110 10 oz | GT-112 12 oz | GT-116 16 oz |
| Weight | oz/yd2 (g/m2) | ASTM D5261 | 3.1 (105) | 3.5 (119) | 4.0 (136) | 4.5 (153) | 6.0 (203) | 7.0 (237) | 8.0 (271) | 10.0 (339) | 12.0 (407) | 16.0 (542) |
| Grab Tensile | lbs (kN) | ASTM D4632 | 80 (0.35) | 90 (0.401) | 100 (0.445) | 120 (0.533) | 160 (0.711) | 180 (0.80) | 205 (0.911) | 250 (1.11) | 300 (1.33) | 380 (1.69) |
| Grab Elongation | % | ASTM D4632 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Trapezoid Tear | lbs (kN) | ASTM D4533 | 25 (0.11) | 40 (0.178) | 50 (0.222) | 50 (0.222) | 65 (0.289) | 75 (0.333) | 85 (0.378) | 100 (0.444) | 115 (0.511) | 145 (0.644) |
| Puncture Resistance | lbs (kN) | ASTM D4833 | 30 (0.13) | 60 (0.267) | 65 (0.289) | 70 (0.311) | 90 (0.40) | 105 (0.467) | 130 (0.578) | 160 (0.711) | 180 (0.80) | 240 (1.07) |
| Mullen Burst | psi (kPa) | ASTM D3786 | 130 (896) | 185 (1275) | 215 (1481) | 240 (1654) | 315 (2170) | 350 (2412) | 400 (2756) | 520 (3583) | 600 (4134) | 750 (5168) |
| Permittivity* | sec-1 | ASTM D4491 | 2.2 | 2.2 | 2 | 1.8 | 1.6 | 1.5 | 1.4 | 1.2 | 1 | 0.7 |
| Water Flow* | gpm/ft2 (1/min/m2) | ASTM D4491 | 150 (6095) | 150 (6095) | 140 (5689) | 120 (4885) | 110 (4480) | 100 (4074) | 90 (3657) | 80 (3251) | 75 (3055) | 50 (2035) |
| A.O.S.* | U.S. Sieve (mm) | ASTM D4751 | 50 (0.30) | 70 (0.212) | 70 (0.212) | 70 (0.212) | 70 (0.212) | 70 (0.212) | 80 (0.180) | 100 (0.150) | 100 (0.150) | 100 (0.150) |
| U.V. Resistance | %/hrs | ASTM D4355 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 | 70/500 |
| FUNCTIONS: SEPARATION, FILTRATION, SOIL REINFORCEMENT, EROSION CONTROL | ||||||||||||
| PACKAGING | ||||||||||||
| Width | 3.9mts or 6mts. | |||||||||||
| Length | Normally, 500mts per roll. But it can be made to order. | |||||||||||
